Main technical parameters
|
产量yield |
150-200kg/h |
|
适用电压 Applicable voltage |
380v/50hz/3ph （可根据客户要求定制can be customized according to customer requirements） |
|
螺杆screw |
直径120mm，长度2400mm，材质38CR，排气式螺杆； Diameter:120mm, length:2400mm, material: 38CR with vent, exhaust screw; |
|
齿轮箱Gear box |
采用国标ZLYJ：200型; ZLYJ：200; |
|
电机Motor |
37KW |
|
变频器Inverter |
采用国际知名品牌：丹佛斯·海利普37kw； Adopt international famous brand: HOLIP37kw； |
|
模头screen changer |
液压上下板尺寸：220mm*220mm；工作压力：≤35Mpa Hydraulic upper and lower plate size:220mm * 220mm; working pressure: ≤ 35MPa |
|
电箱Control box |
温控显示：6区；电器采用国内外知名品牌施耐德与正泰产品 Temperature control display: 6 Zone; Schneider and China ZHENGTAI products are used for electrical appliances |
|
电热圈Heating |
材质：陶瓷；加热电压：220V/50Hz；加热功率：2kw-3kw； Material: Ceramic；Heating voltage: 220 V / 50 Hz；Heating power: 2kw-3kw; |
|
普通料斗Hopper |
开放式平行料斗Open parallel hopper |
|
切粒Pelletizing |
高速旋转2把刀；Knife: two；Hot cutting; |
|
甩干机Dryer |
电机5.5kw；motor：5.5kw |
|
油箱oil box |
电机：1.5kw，电磁阀启动；请加液压油：46号或68号；蓄油量：40L； Motor: 1.5kw, solenoid valve starts;hydraulic oil: 46 or 68;Oil storage capacity: 40L; |
|
随机配件 Random accessories |
工具箱（按钮开关、加热棒、电热偶、剪刀、铲刀、钳子等随机配送） Tool box (button switch, heating rod, electric couple, scissors, shovel, pliers, etc. are randomly distributed) |
